TESTO Saveris Series - Wall Mounting of Data Loggers; Wall Mounting of T1;T1 D;T2;T2 D;Pt;Ptd;H4 D Radio Data Loggers

6 Commissioning
68
6.10.3 Wall mounting of data loggers
6.10.3.1 Wall mounting of T1/T1D/T2/T2D/Pt/PtD/H4D radio
data loggers
When selecting the location, take into account the following points:
• The range of the radio data logger must not be exceeded.
• Attach the radio data logger in such a way that the readings cannot
be falsified, e.g. by exposure to direct solar radiation.
The mounting materials (screws, dowels, etc.) are not included in the
scope of delivery.
1
Position wall bracket at
the required location.
2
Using a pen, mark the locations for the fastening screws.
The distance between the fastening screws is 30 mm.
3
Prepare the fastening location for the attachment in accordance with
the material (e.g. drill hole, insert dowel).
4
Fasten wall bracket using appropriate screws.
The wall bracket must be screwed on with the smooth surface facing
the wall.
