6 Commissioning
20
2
Ensure that cabling cannot be pulled out using a cable tie at the eyelets
for strain relief .
3
Connect mains plug to the power supply.

The Saveris base automatically starts up and is ready for operation
once the language has been selected on the base.
6.4.2 Power supply via plug-in/screw connection
(optional)
1
Loosen clamping screws no. 1 and no. 2.
2
Put cable into the terminals as shown in the illustration. Observe
permissible operating voltage!

The Saveris base automatically starts up and is ready for operation
once the language has been selected on the base.
3
Tighten clamping screws.
4
Ensure that cabling cannot be pulled out using a cable tie at the eyelets
for strain relief .
