TESTO Saveris Series User Manual

8 Technical data
97
8 Technical data
8.1 testo Saveris base
Feature Value
Memory
40,000 values per channel (total max.
18,000,000 values)
Dimensions
225 x 150 x 49 mm
Weight
Approx. 1510 g
Protection class
IP42
Housing material
Die-cast zinc / plastic
Radio frequency
868 MHz / 2.4 GHz
Power supply
6.3 V DC mains unit; alternatively via 24 V
AC/DC plug-in/screw terminals, power
consumption < 4 W.
Batteries
4
Li-ion rechargeable battery
The battery is used only for backing up data
and for an emergency SMS in the event of a
failure of the power supply, not for power
supply during operation.
Operating temperature
+5 to +45°C
Storage temperature
-20 to +60°C
Display
Graphical LCD, 4 control keys
Interfaces
USB, radio, Ethernet
Number of Saveris radio data
loggers
Max. 15 probes can be connected directly via
radio interfaces,
Max. 150 in total via radio / router / converter /
extender and Ethernet,
Max. 450 channels.
Alarm relay Max. 1 A, max. 30 W, max. 60/25 V DC/AC,
NC or NO contact
GSM module
850 / 900 / 1800 / 1900 MHz
Mounting
Table base and wall bracket included
4
Wearing part

TESTO Saveris Series Specifications

General

Measurement Parameters	Temperature, Humidity, CO2, Pressure, Differential Pressure
Humidity Range	0 to 100 %RH
CO2 Range	0 to 5000 ppm
Communication	Ethernet, WiFi, USB
Data Storage	Internal memory
Alarm	Visual and audible alarms
Power Supply	Battery, Mains power
Software	Testo Saveris software
