8 Technical data
115
Feature Value
Power supply
6.3 V DC mains unit;
alternatively via 24 V AC/DC plug-in/screw
terminals,
PoE, power consumption < 2 W
Housing material
Plastic
Protection class
IP54
Operating temperature
-20 to +50°C
Storage temperature
-40 to +60°C
Interfaces
Radio, Ethernet
Number of radio probes
Max. 100
Radio frequency
868 MHz
Wall bracket
Included
8.9 BT Gateway for testo 182
Feature Value
Housing material
PC ABS
Dimensions (W x H x D)
Approx. 95 x 68 x 48 mm
Weight
90 g
Protection class
IP20
Storage temperature
-20°C to +70°C
Operating temperature
0°C to +50°C
Humidity
0 to 95% (non-condensing)
Power supply
Mains adapter 5 VDC (USB) / PoE
Interfaces
LAN / USB
Memory capacity
1500 data records (BTLE data logger)
Recording interval
The gateway constantly searches for data
loggers (BTLE)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TESTO Saveris Series and is the answer not in the manual?

TESTO Saveris Series Specifications

General IconGeneral
Measurement ParametersTemperature, Humidity, CO2, Pressure, Differential Pressure
Humidity Range0 to 100 %RH
CO2 Range0 to 5000 ppm
CommunicationEthernet, WiFi, USB
Data StorageInternal memory
AlarmVisual and audible alarms
Power SupplyBattery, Mains power
SoftwareTesto Saveris software
