6 Commissioning
71
• The maximum range of the reader in free field is at most 30 metres
(Bluetooth
®
).
• The BT Gateway for testo 182 may only be operated inside buildings
(protection class IP20).
Wall mounting
Make sure that the USB wireless
stick is inserted into USB port 2.
Mount BT Gateway for testo 182
Option 1:
• Hang on the wall via the hook
eyelet on the bottom of the
gateway housing.
Option 2:
• Mount the top-hat rail (not included
in the scope of delivery) and click
the Gateway into place on the top-
hat rail.
Option 3:
• Use double-sided adhesive tape to
attach the Gateway to a clean
surface
.
Carry out the necessary wiring.
