13.5.3 Sleep
Class Subclass Name Type Min Max Default Unit Description
Power Sleep Sleep Current I2 0 32767 10 mA |Current()| threshold to enter SLEEP mode
Power Sleep Voltage Time U1 0 255 5 s Voltage sampling period in SLEEP mode
Power Sleep Current Time U1 0 255 20 s Current sampling period in SLEEP mode
Power Sleep
Wake
Comparator
H1 0x00 0xFF 0x00
Wake Comparator Configuration Setting
Bits 7–4: Reserved
Bits 3–2: Wk1, WK0—Wake Comparator
Threshold
0,0 = ±0.625 mV
0,1 = ±1.25 mV
1,0 = ±2.5 mV
1,1 = ±5 mV
Bits 1–0: Reserved
13.5.4 Ship
Class Subclass Name Type Min Max Default Unit Description
Power Ship FET OFF time U1 0 127 10 s
Delay time to turn OFF FETs prior to entering
SHUTDOWN mode. This setting should not be
longer than the Ship Delay setting.
Power Ship Delay U1 0 254 20 s
Delay time to enter SHUTDOWN mode after
FETs are turned OFF
Power Ship Auto Ship Time U2 0 65535 1440 min
The device will automatically enter SHUTDOWN
mode after staying in SLEEP mode without
communicating for this amount of time when
Power Config[AUTO_SHIP_EN] = 1.
13.6 Gas Gauging
13.6.1 Standby
Class Subclass Name Type Min Max Default Unit Description
Gas Gauging Standby Standby Current I2 –32768 0 –10 mA
13.6.2 Max Load
Class Subclass Name Type Min Max Default Unit Description
Gas Gauging Max Load
Max Load
Current
I2 –32768 32767 –500 mA
Gas Gauging Max Load
Max Load
RSOC
U1 0 100 50 %
13.6.3 Current Thresholds
Class Subclass Name Type Min Max Default Unit Description
Gas Gauging
Current
Thresholds
Dsg Current
Threshold
I2 –32768 32767 100 mA DISCHARGE mode Current() threshold
Gas Gauging
Current
Thresholds
Chg Current
Threshold
I2 –32768 32767 50 mA CHARGE mode Current() threshold
Gas Gauging
Current
Thresholds
Quit Current I2 0 32767 10 mA |Current()| threshold to enter REST mode
Gas Gauging
Current
Thresholds
Dsg Relax Time U1 0 255 1 mA Discharge to relax timeout
Gas Gauging
Current
Thresholds
Chg Relax Time U1 0 255 60 mA Charge to relax timeout
13.6.4 Design
Class Subclass Name Type Min Max Default Unit Description
Gas Gauging Design
Design Capacity
mAh
I2 0 32767 4400 mAh Design Capacity in mAh
www.ti.com Data Flash Values
SLUUCO0 – APRIL 2022
Submit Document Feedback
BQ28Z610-R2 105
Copyright © 2022 Texas Instruments Incorporated
