Texas Instruments BQ28Z610-R2 User Manual

Class Subclass Name Type Min Max Default Unit Description
Gas Gauging Design
Design Capacity
cWh
I2 0 32767 6336 cWh Design Capacity in cWh
Gas Gauging Design Design Voltage I2 0 32767 7200 mV Design Voltage
13.6.5 Cycle
Class Subclass Name Type Min Max Default Unit Description
Gas Gauging Cycle
Cycle Count
Percentage
U1 0 100 90 % Cycle Count Percentage
13.6.6 FD
Class Subclass Name Type Min Max Default Unit Description
Gas Gauging FD Set Voltage Threshold I2 0 5000 3000 mV BatteryStatus()[FD] cell voltage set threshold
Gas Gauging FD
Clear Voltage
Threshold
I2 0 5000 3100 mV BatteryStatus()[FD] cell voltage clear threshold
Gas Gauging FD
Set RSOC %
Threshold
U1 0 100 0 %
BatteryStatus()[FD]RelativeStateOfCharge() set
threshold
Gas Gauging FD
Clear RSOC %
Threshold
U1 0 100 5 %
BatteryStatus()[FD]RelativeStateOfCharge() clear
threshold
13.6.7 FC
Class Subclass Name Type Min Max Default Unit Description
Gas Gauging FC Set Voltage Threshold I2 0 5000 4200 mV BatteryStatus()[FC] cell voltage set threshold
Gas Gauging FC
Clear Voltage
Threshold
I2 0 5000 4100 mV BatteryStatus()[FC] cell voltage clear threshold
Gas Gauging FC
Set RSOC %
Threshold
U1 0 100 100 %
BatteryStatus()[FC]RelativeStateOfCharge() set
threshold
Gas Gauging FC
Clear RSOC %
Threshold
U1 0 100 95 %
BatteryStatus()[FC]RelativeStateOfCharge() clear
threshold
13.6.8 TDA
Per the Smart Battery Data Specification v1.1, TDA is only active while discharging.
Class Subclass Name Type Min Max Default Unit Description
Gas Gauging TD
Set Voltage
Threshold
I2 0 5000 3200 mV GaugingStatus[TD] cell voltage set threshold
Gas Gauging TD
Clear Voltage
Threshold
I2 0 5000 3300 mV GaugingStatus[TD] cell voltage clear threshold
Gas Gauging TD
Set RSOC %
Threshold
U1 0 100 6 %
GaugingStatus[TD]RelativeStateOfCharge() set
threshold
Gas Gauging TD
Clear RSOC %
Threshold
U1 0 100 8 %
GaugingStatus[TD]RelativeStateOfCharge()
clear threshold
13.6.9 TCA
Per the Smart Battery Data Specification v1.1, TCA is only active while charging.
Class Subclass Name Type Min Max Default Unit Description
Gas
Gauging
TC Set Voltage Threshold I2 0 5000 4200 mV GaugingStatus[TC] cell voltage set threshold
Gas
Gauging
TC
Clear Voltage
Threshold
I2 0 5000 4100 mV GaugingStatus[TC] cell voltage clear threshold
Gas
Gauging
TC
Set RSOC %
Threshold
U1 0 100 100 %
GaugingStatus[TC]RelativeStateOfCharge() set
threshold
Gas
Gauging
TC
Clear RSOC %
Threshold
U1 0 100 95 %
GaugingStatus[TC]RelativeStateOfCharge() clear
threshold
Data Flash Values www.ti.com
106 BQ28Z610-R2 SLUUCO0 – APRIL 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
