14.1 Data Flash Table

Table 14-1. Data Flash Table

Class Subclass Address Name Type Min Value Max Value Default Units

Calibration Voltage 0x4000 Cell Gain I2 –32767 32767 12101 —

Calibration Voltage 0x4002 Pack Gain U2 0 65535 49669 —

Calibration Voltage 0x4004 BAT Gain U2 0 65535 48936 —

Calibration Current 0x4006 CC Gain F4 1.00E–01 4.00E+00 3.58422 —

Calibration Current 0x400A Capacity Gain F4 2.98262E+04

1.193046E+

1069035.25

—

Calibration Current Offset 0x400E CC Offset I2 –32767 32767 0 —

Calibration Current Offset 0x4010

Coulomb Counter Offset

Samples

U2 0 65535 64 —

Calibration Current Offset 0x4012 Board Offset I2 –32768 32767 0 —

Calibration Current Offset 0x40C0 CC Auto Config H1 0x00 0x07 0x03 Hex

Calibration Current Offset 0x40C1 CC Auto Offset I2 –10000 10000 0 —

Calibration Temperature 0x4014 Internal Temp Offset I1 –128 127 0 0.1°C

Calibration Temperature 0x4015 External1 Temp Offset I1 –128 127 0 0.1°C

Calibration

Internal Temp

Model

0x4400 Int Gain I2 –32768 32767 –12143 —

Calibration

Internal Temp

Model

0x4402 Int base offset I2 –32768 32767 6232 —

Calibration

Internal Temp

Model

0x4404 Int Minimum AD I2 –32768 32767 0 —

Calibration

Internal Temp

Model

0x4406 Int Maximum Temp I2 –32768 32767 6232 0.1 K

Calibration

Cell Temperature

Model

0x4408 Coeff a1 I2 –32768 32767 –11130 —

Calibration

Cell Temperature

Model

0x440A Coeff a2 I2 –32768 32767 19142 —

Calibration

Cell Temperature

Model

0x440C Coeff a3 I2 –32768 32767 –19262 —

Calibration

Cell Temperature

Model

0x440E Coeff a4 I2 –32768 32767 28203 —

Calibration

Cell Temperature

Model

0x4410 Coeff a5 I2 –32768 32767 892 —

Calibration

Cell Temperature

Model

0x4412 Coeff b1 I2 –32768 32767 328 —

Calibration

Cell Temperature

Model

0x4414 Coeff b2 I2 –32768 32767 –605 —

Calibration

Cell Temperature

Model

0x4416 Coeff b3 I2 –32768 32767 –2443 —

Calibration

Cell Temperature

Model

0x4418 Coeff b4 I2 –32768 32767 4696 —

Calibration

Cell Temperature

Model

0x441A Rc0 I2 –32768 32767 11703 —

Calibration

Cell Temperature

Model

0x441C Adc0 I2 –32768 32767 11703 —

Chapter 14

Data Flash Summary

www.ti.com Data Flash Summary

SLUUCO0 – APRIL 2022

Submit Document Feedback

BQ28Z610-R2 119
