LDMD (Bit 3): LOAD mode
1 = Constant oower
0 = Constant current
R_DIS (Bit 2): Resistance updates
1 = Disabled
0 = Enabled
VOK (Bit 1): Voltage OK for QMax updates
1 = Detected
0 = Not detected
QMax (Bit 0): QMax updates. This bit toggles after every QMax update.
12.1.2 0x02/03 AtRate()
This read/write word function sets the value used in calculating AtRateTimeToFull() and AtRateTimeToEmpty().
SBS Cmd Name
Access
Proto-
col
Type Min Max Default Unit
SE US FA
0x02/03 AtRate() R/W Word I2 –32768 32767 0 mA
12.1.3 0x04/05 AtRateTimeToEmpty()
This read-word function returns the remaining time to fully discharge the battery stack.
SBS
Cmd
Name
Access
Proto-
col
Type Min Max Unit Note
SE US FA
0x04/05 AtRateTimeToEmpty() R Word U2 0 65535 min
65535 indicates not being
charged
12.1.4 0x06/07 Temperature()
This read-word function returns the temperature in units 0.1 K.
SBS Cmd Name
Access
Proto-
col
Type Min Max Unit
SE US FA
0x06/07 Temperature() R Word U2 0 65535 0.1 K
12.1.5 0x08/09 Voltage()
This read-word function returns the sum of the measured cell voltages.
SBS Cmd Name
Access
Proto-
col
Type Min Max Unit
SE US FA
0x08/09 Voltage() R Word U2 0 65535 mV
12.1.6 0x0A/0B BatteryStatus()
This read-word function returns various battery status information.
