IN (Bit 12): Charge Inhibit
1 = Active
0 = Inactive
HV (Bit 11): High Voltage Region
1 = Active
0 = Inactive
MV (Bit 10): Mid Voltage Region
1 = Active
0 = Inactive
LV (Bit 9): Low Voltage Region
1 = Active
0 = Inactive
PV (Bit 8): Precharge Voltage Region
1 = Active
0 = Inactive
OT (Bit 6): Over Temperature Region
1 = Active
0 = Inactive
HT (Bit 5): High Temperature Region
1 = Active
0 = Inactive
STH (Bit 4): Standard Temperature High Region
1 = Active
0 = Inactive
RT (Bit 3): Room Temperature Region
1 = Active
0 = Inactive
STL (Bit 2): Standard Temperature Low Region
1 = Active
0 = Inactive
LT (Bit 1): Low Temperature Region
1 = Active
0 = Inactive
UT (Bit 0): Under Temperature Region
1 = Active
0 = Inactive
12.2.32 MACSubcmd() 0x0056 GaugingStatus
This command returns the GaugingStatus() flags on MACData().
Note
The Battery Management Studio (bqStudio) tool splits the returned value of GaugingStatus() into two
separate registers: GaugingStatus = Lowest Byte, and ITStatus = 2nd and 3rd bytes, with the 4th byte
reserved.
www.ti.com I2C Commands
SLUUCO0 – APRIL 2022
Submit Document Feedback
BQ28Z610-R2 85
Copyright © 2022 Texas Instruments Incorporated
