RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD
DFET
F
CFET
F
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD RSVD RSVD VIMA VIMR RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD RSVD SOV RSVD
RSVD (Bits 31–18): Reserved
DFETF (Bit 17): Discharge FET Failure
1 = Detected
0 = Not Detected
CFETF (Bit 16): Charge FET Failure
1 = Detected
0 = Not Detected
RSVD (Bits 15–13): Reserved
VIMR (Bit 12): Voltage Imbalance While Pack Is At Rest Failure
1 = Detected
0 = Not Detected
VIMA (Bit 11): Voltage Imbalance While Pack Is Active Failure
1 = Detected
0 = Not Detected
RSVD (Bits 10–2): Reserved
SOV (Bit 1): Safety Cell Overvoltage Failure
1 = Detected
0 = Not Detected
RSVD (Bit 0): Reserved
12.2.30 MACSubcmd() 0x0054 OperationStatus
This command returns the OperationStatus() flags on MACData().
Status Condition Action
Activate 0x0054 to MACSubcmd() Outputs OperationStatus() flags on MACData()
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD RSVD
EM
SHUT
CB
SLP
CC
SLP
AD
SMBL
CAL
INIT
SLEEP
M
XL
CAL_O
FF
SET
CAL
AUTO
CALM
AUTH RSVD SDM
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SLEEP SEC1 SEC0 PF SS SDV SEC1 SEC0 RSVD RSVD RSVD RSVD RSVD CHG DSG RSVD
RSVD (Bits 31–30): Reserved
EMSHUT (Bit 29): Emergency FET Shutdown
