13.11.2 VIMR—Voltage Imbalance at Rest
Class Subclass Name Type Min Max Default Unit Description
Permanent
Fail
VIMR Check Voltage I2 0 5000 3600 mV Voltage Imbalance at Rest Check Voltage
Permanent
Fail
VIMR Check Current I2 0 32767 10 mA Voltage Imbalance at Rest Check Current
Permanent
Fail
VIMR Delta
Threshold
I2 0 5000 200 mV Voltage Imbalance at Rest Trip Threshold
Permanent
Fail
VIMR Delay U1 0 255 2 s Voltage Imbalance at Rest Check Trip
Delay
Permanent
Fail
VIMR Duration U2 0 65535 100 s Voltage Imbalance at Rest Check Duration
13.11.3 VIMA—Voltage Imbalance Active
Class Subclass Name Type Min Max Default Unit Description
Permanent Fail VIMA Check Voltage I2 0 5000 3600 mV Voltage Imbalance active Check Voltage
Permanent Fail VIMA Check Current I2 0 32767 10 mA Voltage Imbalance active Check Current
Permanent Fail VIMA Delta Threshold I2 0 5000 300 mV Voltage Imbalance active trip threshold
Permanent Fail VIMA Delay U1 0 255 2 s Voltage Imbalance active Check trip delay
13.12 PF Status
The data in this class is saved at the time of the PF event.
13.12.1 Device Status Data
Class Subclass Name Type Min Max Default Unit Description
PF Status Device Status Data Safety Alert A H1 0 FF 0 hex Accumulated safety flags since PF event
PF Status Device Status Data Safety Status A H1 0 FF 0 hex Accumulated safety flags since PF event
Name: Safety Alert A or Safety Status A
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
RSVD AOLD RSVD OCD RSVD OCC COV CUV
Class Subclass Name Type Min Max Default Unit Description
PF Status Device Status Data Safety Alert B H1 0 FF 0 hex Accumulated safety flags since PF event
PF Status Device Status Data Safety Status B H1 0 FF 0 hex Accumulated safety flags since PF event
Name: Safety Alert B or Safety Status B
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
RSVD RSVD OTD OTC RSVD ASCD RSVD ASCC
Class Subclass Name Type Min Max Default Unit Description
PF Status Device Status Data Safety Alert C H1 0 FF 0 hex Accumulated safety flags since PF event
PF Status Device Status Data Safety Status C H1 0 FF 0 hex Accumulated safety flags since PF event
Name: Safety Alert C or Safety Status C
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
RSVD RSVD CTOS RSVD PTOS RSVD RSVD RSVD
Class Subclass Name Type Min Max Default Unit Description
PF Status Device Status Data Safety Alert D H1 0 FF 0 hex
Accumulated safety flags since PF event. All bits in this
register are RSVD.
PF Status Device Status Data Safety Status D H1 0 FF 0 hex Accumulated safety flags since PF event
www.ti.com Data Flash Values
SLUUCO0 – APRIL 2022
Submit Document Feedback
BQ28Z610-R2 113
Copyright © 2022 Texas Instruments Incorporated
