12.2.12 MACSubcmd() 0x0012 Device Reset
This command resets the device.
Status Condition Action
Enable 0x0012 to MACSubcmd() Resets the device
Note
Command 0x0041 also resets the device.
12.2.13 MACSubcmd() 0x001F CHG FET
This command turns on/off CHG FET drive function to ease testing during manufacturing.
Status Condition Action
Disable
ManufacturingStatus()[FET,CHG] = 0,1 AND
0x001F to MACSubcmd()
ManufacturingStatus()[FET,CHG] = 0,0
CHG FET turns off
Enable
ManufacturingStatus()[FET,CHG] = 0,0 AND
0x001F to MACSubcmd()
ManufacturingStatus()[FET,CHG] = 0,1
CHG FET turns on if no safety condition override.
12.2.14 MACSubcmd() 0x0020 DSG FET
This command turns on/off DSG FET drive function to ease testing during manufacturing.
Status Condition Action
Disable
ManufacturingStatus()[FET,DSG] = 0,1 AND
0x0020 to MACSubcmd()
ManufacturingStatus()[FET,DSG] = 0,0
DSG FET turns off
ManufacturingStatus()[FET,DSG] = 0,0 AND 0x0020 to
MACSubcmd()
Enable
ManufacturingStatus()[FET,DSG] = 0,1
DSG FET turns on if no safety condition override.
12.2.15 MACSubcmd() 0x0021 Gauging
This command enables or disables the gauging function to ease testing during manufacturing.
Status Condition Action
Disable
ManufacturingStatus()[Gauge] = 1 AND
0x0021 to MACSubcmd()
ManufacturingStatus()[Gauge] = 0
Disables gauging feature
Enable
ManufacturingStatus()[Gauge] = 0 AND
0x0021 to MACSubcmd()
ManufacturingStatus()[Gauge] = 1
Enable gauging feature
12.2.16 MACSubcmd() 0x0022 FET Control
This command disables/enables control of the CHG, DSG, and PCHG FETs by the firmware.
Status Condition Action
Disable
ManufacturingStatus()[FET] = 1 AND
0x0022 to MACSubcmd()
ManufacturingStatus()[FET] = 0
CHG and DSG FETs are disabled and remain OFF.
Enable
ManufacturingStatus()[FET] = 0 AND
0x0022 to MACSubcmd()
ManufacturingStatus()[FET] = 1
CHG and DSG FETs are controlled by the firmware.
12.2.17 MACSubcmd() 0x0023 Lifetime Data Collection
This command disables/enables Lifetime data collection for ease of manufacturing.
Status Condition Action
Disable
ManufacturingStatus()[LF] = 1 AND
0x0023 to MACSubcmd()
ManufacturingStatus()[LF] = 0
Lifetime Data collection feature is disabled.
