Name: Safety Status D
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
RSVD RSVD CTOS RSVD PTOS DFW RSVD IFC
Class Subclass Name Type Min Max Default Unit Description
PF Status
Device Status
Data
Operation Status A H2 0 FFFF 0 hex OperationStatus() data at the time of the PF event
Name: Operation Status A
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
RSVD RSVD RSVD RSVD PCHG CHG DSG RSVD SLEEP XCHG XDSG PF SS SDV SEC1 SEC0
Class Subclass Name Type Min Max Default Unit Description
PF Status
Device Status
Data
Operation Status B H2 0 FFFF 0 hex OperationStatus() data at the time of the PF event
Name: Operation Status B
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
SLEEPM XL
CAL_OF
FSET
CAL
AUTO
CALM
AUTH LED SDM RSVD RSVD RSVD CB SLPCC SLPAD
SMBL
CAL
INIT
Class Subclass Name Type Min Max Default Unit Description
PF Status Device Status Data Temp Range H1 0 FF 0 hex
Temperature range status at the time of the PF
event. The temperature range information is returned to
ChargingStatus().
Name: Temp Range
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
RSVD OT HT STH RT SLT LT UT
Class Subclass Name Type Min Max Default Unit Description
PF Status Device Status Data Charging Status A H1 0 FF 0 hex
The charging status at the time of the PF event. See
section under MACSubcmd(), Gauging Status().
Name: Charging Status A
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
VCT MCHG SU IN HV MV LV PV
Class Subclass Name Type Min Max Default Unit Description
PF Status Device Status Data Gauging Status H1 0 FF 0 hex
The charging status at the time of the PF event. See
section under MACSubcmd(), Gauging Status().
Name: Gauging Status
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
VCT MCHG SU IN HV MV LV PV
Class Subclass Name Type Min Max Default Unit Description
PF Status Device Status Data IT Status H2 0 FFFF 0 hex
The Impedance Track status at the time of the PF event.
See section under MACSubcmd(), Gauging Status().
Name: IT Status
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
NSFM RSVD
SLPQMa
x
QEN VOK RDIS RSVD REST RSVD RSVD RSVD OCVFR LDMD RX QMax VDQ
13.12.2 Device Voltage Data
Class
Subclass Name Type Min Max Default Unit Description
PF Status Device Voltage Data Cell Voltage 0 I2 –32768 32767 0 mV Cell 0 voltage
PF Status Device Voltage Data Cell Voltage 1 I2 –32768 32767 0 mV Cell 1 voltage
PF Status Device Voltage Data Bat Direct Voltage I2 –32768 32767 0 mV Cell stack voltage
PF Status Device Voltage Data Pack Voltage I2 –32768 32767 0 mV Pack terminal voltage
