15.1 Overload in Discharge Protection (AOLD)
Table 15-1. Overload in Discharge Protection Threshold
(Settings:AFE:AFE Protection Control [RSNS] = 0)
OLD Threshold ([RSNS] = 0)
(1)
Setting Threshold Setting Threshold
0x00 –8.30 mV 0x08 –30.54 mV
0x01 –11.08 mV 0x09 –33.32 mV
0x02 –13.86 mV 0x0A –36.10 mV
0x03 –16.64 mV 0x0B –38.88 mV
0x04 –19.42 mV 0x0C –41.66 mV
0x05 –22.20 mV 0x0D –44.44 mV
0x06 –24.98 mV 0x0E –47.22 mV
0x07 –27.76 mV 0x0F –50.00 mV
(1) The data flash setting Protection:AFE Thresholds:OLD Threshold[3:0] sets the voltage threshold.
Table 15-2. Overload in Discharge Protection Threshold
(Settings:AFE:AFE Protection Control [RSNS] = 1)
OLD Threshold ([RSNS] = 1)
(1)
Setting Threshold Setting Threshold
0x00 –16.60 mV 0x08 –61.08 mV
0x01 –22.16 mV 0x09 –66.64 mV
0x02 –27.72 mV 0x0A –72.20 mV
0x03 –33.28 mV 0x0B –77.76 mV
0x04 –38.84 mV 0x0C –83.32 mV
0x05 –44.40 mV 0x0D –88.88 mV
0x06 –49.96 mV 0x0E –94.44 mV
0x07 –55.52 mV 0x0F –100.00 mV
(1) The data flash setting Protection:AFE Thresholds:OLD Threshold[3:0] sets the voltage threshold.
Table 15-3. Overload in Discharge Protection Delay
Setting
(1)
Time Setting Time Setting Time Setting Time
0x00 1 ms 0x04 9 ms 0x08 17 ms 0x0C 25 ms
0x01 3 ms 0x05 11 ms 0x09 19 ms 0x0D 27 ms
0x02 5 ms 0x06 13 ms 0x0A 21 ms 0x0E 29 ms
0x03 7 ms 0x07 15 ms 0x0B 23 ms 0x0F 31 ms
(1) The data flash setting Protection:AFE Thresholds:OLD Threshold[7:4] sets the delay time.
Chapter 15
AFE Threshold and Delay Settings
www.ti.com AFE Threshold and Delay Settings
SLUUCO0 – APRIL 2022
Submit Document Feedback
BQ28Z610-R2 129
Copyright © 2022 Texas Instruments Incorporated
