Class Subclass Name Type Min Max Default Unit Description
RA Table R_a0 Cell 0 R_A 5 I2 –32768 32768 42 2
–10
Ω Cell 0 resistance at grid point 5
RA Table R_a0 Cell 0 R_A 6 I2 –32768 32768 45 2
–10
Ω Cell 0 resistance at grid point 6
RA Table R_a0 Cell 0 R_A 7 I2 –32768 32768 48 2
–10
Ω Cell 0 resistance at grid point 7
RA Table R_a0 Cell 0 R_A 8 I2 –32768 32768 49 2
–10
Ω Cell 0 resistance at grid point 8
RA Table R_a0 Cell 0 R_A 9 I2 –32768 32768 52 2
–10
Ω Cell 0 resistance at grid point 9
RA Table R_a0 Cell 0 R_A 10 I2 –32768 32768 56 2
–10
Ω Cell 0 resistance at grid point 10
RA Table R_a0 Cell 0 R_A 11 I2 –32768 32768 64 2
–10
Ω Cell 0 resistance at grid point 11
RA Table R_a0 Cell 0 R_A 12 I2 –32768 32768 74 2
–10
Ω Cell 0 resistance at grid point 12
RA Table R_a0 Cell 0 R_A 13 I2 –32768 32768 128 2
–10
Ω Cell 0 resistance at grid point 13
RA Table R_a0 Cell 0 R_A 14 I2 –32768 32768 378 2
–10
Ω Cell 0 resistance at grid point 14
13.13.2 R_a1
Class Subclass Name Type Min Max Default Unit Description
RA Table R_a1 Cell 1 R_A Flag H2 0x0000 0xFFFF 0xFF55
High-Byte:
0x00: Cell Impedance and QMax updated
0x05: RELAX mode and QMax update in progress
0x55: DISCHARGE mode and cell updated
0xFF: cell impedance never updated Low-Byte:
0x00: Table not used and QMax updated
0x55: Table being used
0xFF: Table never used, no QMax or cell impedance update
RA Table R_a1 Cell 1 R_A 0 I2 –32768 32768 38 2
–10
Ω Cell 1 resistance at grid point 0
RA Table R_a1 Cell 1 R_A 1 I2 –32768 32768 41 2
–10
Ω Cell 1 resistance at grid point 1
RA Table R_a1 Cell 1 R_A 2 I2 –32768 32768 43 2
–10
Ω Cell 1 resistance at grid point 2
RA Table R_a1 Cell 1 R_A 3 I2 –32768 32768 44 2
–10
Ω Cell 1 resistance at grid point 3
RA Table R_a1 Cell 1 R_A 4 I2 –32768 32768 42 2
–10
Ω Cell 1 resistance at grid point 4
RA Table R_a1 Cell 1 R_A 5 I2 –32768 32768 42 2
–10
Ω Cell 1 resistance at grid point 5
RA Table R_a1 Cell 1 R_A 6 I2 –32768 32768 45 2
–10
Ω Cell 1 resistance at grid point 6
RA Table R_a1 Cell 1 R_A 7 I2 –32768 32768 48 2
–10
Ω Cell 1 resistance at grid point 7
RA Table R_a1 Cell 1 R_A 8 I2 –32768 32768 49 2
–10
Ω Cell 1 resistance at grid point 8
RA Table R_a1 Cell 1 R_A 9 I2 –32768 32768 52 2
–10
Ω Cell 1 resistance at grid point 9
RA Table R_a1 Cell 1 R_A 10 I2 –32768 32768 56 2
–10
Ω Cell 1 resistance at grid point 10
RA Table R_a1 Cell 1 R_A 11 I2 –32768 32768 64 2
–10
Ω Cell 1 resistance at grid point 11
RA Table R_a1 Cell 1 R_A 12 I2 –32768 32768 74 2
–10
Ω Cell 1 resistance at grid point 12
RA Table R_a1 Cell 1 R_A 13 I2 –32768 32768 128 2
–10
Ω Cell 1 resistance at grid point 13
RA Table R_a1 Cell 1 R_A 14 I2 –32768 32768 378 2
–10
Ω Cell 1 resistance at grid point 14
13.13.3 R_a0x
Class Subclass Name Type Min Max Default Unit Description
RA Table R_a0x xCell 0 R_A Flag H2 0x0000 0xFFFF 0xFFFF
High-Byte:
0x00: Cell Impedance and QMax updated
0x05: RELAX mode and QMax update in progress
0x55: DISCHARGE mode and cell updated 0xFF: Cell
impedance never updated.
Low-Byte:
0x00: Table is not used and QMax updated.
0x55: Table is being used.
0xFF: Table was never used and no QMax or cell impedance
was updated.
RA Table R_a0x xCell 0 R_A 0 I2 –32768 32768 38 2
–10
Ω Cell 0 resistance at grid point 0
RA Table R_a0x xCell 0 R_A 1 I2 –32768 32768 41 2
–10
Ω Cell 0 resistance at grid point 1
RA Table R_a0x xCell 0 R_A 2 I2 –32768 32768 43 2
–10
Ω Cell 0 resistance at grid point 2
RA Table R_a0x xCell 0 R_A 3 I2 –32768 32768 44 2
–10
Ω Cell 0 resistance at grid point 3
RA Table R_a0x xCell 0 R_A 4 I2 –32768 32768 42 2
–10
Ω Cell 0 resistance at grid point 4
RA Table R_a0x xCell 0 R_A 5 I2 –32768 32768 42 2
–10
Ω Cell 0 resistance at grid point 5
RA Table R_a0x xCell 0 R_A 6 I2 –32768 32768 45 2
–10
Ω Cell 0 resistance at grid point 6
RA Table R_a0x xCell 0 R_A 7 I2 –32768 32768 48 2
–10
Ω Cell 0 resistance at grid point 7
RA Table R_a0x xCell 0 R_A 8 I2 –32768 32768 49 2
–10
Ω Cell 0 resistance at grid point 8
RA Table R_a0x xCell 0 R_A 9 I2 –32768 32768 52 2
–10
Ω Cell 0 resistance at grid point 9
RA Table R_a0x xCell 0 R_A 10 I2 –32768 32768 56 2
–10
Ω Cell 0 resistance at grid point 10
RA Table R_a0x xCell 0 R_A 11 I2 –32768 32768 64 2
–10
Ω Cell 0 resistance at grid point 11
