Texas Instruments BQ28Z610-R2 User Manual

Class Subclass Name Type Min Max Default Unit Description
Protections COV
Recovery High
Temp
I2 0 32767 3900 mV
Cell overvoltage high temperature
range recovery threshold
Protections COV
Recovery Rec
Temp
I2 0 32767 3900 mV
Cell overvoltage recommended
temperature range recovery threshold
13.10.3 OCC—Overcurrent In Charge
Class Subclass Name Type Min Max Default Unit Description
Protections OCC Threshold I2 –32768 32767 6000 mA
Overcurrent in Charge trip
threshold
Protections OCC Delay U1 0 255 0 s
Overcurrent in Charge trip
delay
Protections OCC
Recovery
Threshold
I2 –32768 32767 200 mA
Overcurrent in Charge
recovery threshold
Protections OCC Recovery Delay U1 0 255 5 s
Overcurrent in Charge
recovery delay
13.10.4 OCD—Overcurrent In Discharge
Class Subclass Name Type Min Max Default Unit Description
Protections OCD Threshold I2 –32768 32767 –6000 mA Overcurrent in Discharge trip threshold
Protections OCD Delay U1 0 255 6 s Overcurrent in Discharge trip delay
Protections OCD Recovery I2 –32768 32767 50 mA Overcurrent in Discharge recovery threshold
Protections OCD Recovery Delay U1 0 255 5 s Overcurrent in Discharge recovery delay
13.10.5 AOLD—AFE Over Load In Discharge
Class Subclass Name Type Min Max Default Unit Description
Protections AOLD Threshold H1 0x00 0xFF 0xF4 hex
AOLD: Threshold
Setting, Bits 7–4: OLDD: AOLD delay time
Setting, Bits 3–0: OLDV: AOLD threshold
Protections AOLD Recovery U1 0 255 5 s Overload recovery time
13.10.6 ASCC—AFE Short Circuit in Charge
Class Subclass Name Type Min Max Default Unit Description
Protections ASCC Threshold H1 0x00 0xFF 0x77 hex
ASCC: Threshold
Setting, Bits 7–4: SCCD: ASCC delay time
Setting, Bit 3: Reserved
Setting, Bits 2–0: OLDV: AOLD threshold Setting
Protections ASCC Recovery U1 0 255 5 s Overload recovery time
13.10.7 ASCD—AFE Short Circuit in Discharge
Class Subclass Name Type Min Max Default Unit Description
Protections ASCD Threshold 1 H1 0x00 0xFF 0x77 hex
ASCD: Threshold 1
Setting, Bits 7–4: SCD1D: SCD1 delay time
Setting, Bit 3: Reserved
Setting, Bits 2–0: SCD1V: SCD1 threshold setting
Protections ASCD Threshold 2 H1 0x00 0xFF 0xE7 hex
ASCD: Threshold 2
Setting, Bits 7–4: SCD2D: SCD2 delay time
Setting, Bit 3: Reserved
Setting, Bits 2–0: SCD2V: SCD2 threshold setting
Protections ASCD Recovery U1 0 255 5 s Overload recovery time
13.10.8 OTC—Overtemperature in Charge
Class Subclass Name Type Min Max Default Unit Description
Protections OTC Threshold I2 –400 1500 550 0.1°C Overtemperature in Charge trip threshold
Protections OTC Delay U1 0 255 2 s Overtemperature in Charge Cell trip delay
