Texas Instruments BQ28Z610-R2

13.1 Data Formats
13.1.1 Unsigned Integer
Unsigned integers are stored without changes as 1-byte, 2-byte, or 4-byte values in Little Endian byte order.
0
U1
MSB
0 1
U2
LSB
U2
MSB
0 1 2 3
U4 L
LSB
U4 L
MSB
U4 H
LSB
U4 H
MSB
13.1.2 Integer
Integer values are stored in 2's-complement format in 1-byte, 2-byte, or 4-byte values in Little Endian byte order.
0
I1
MSB
0 1
I2
LSB
I2
MSB
0 1 2 3
I4 L
LSB
I4 L
MSB
I4 H
LSB
I4 H
MSB
13.1.3 Floating Point
Floating point values are stored using the IEEE754 Single Precision 4-byte format in Little Endian byte order.
0 1 2 3
Fract [0–7] Fract [8–15]
Exp[0] +
Fract[16–22]
Sign + Exp[1–7]
Where:
Chapter 13
Data Flash Values
