Status Condition Action
Normal DSG FET off AND Current() > DFET:OFF Threshold PFAlert()[DFETF] = 0
Alert DSG FET off AND Current() ≤ DFET:OFF Threshold PFAlert()[DFETF] = 1
Trip
DSG FET off AND Current() continuously ≤ DFET:OFF Threshold
for DFET:OFF Delay duration
PFAlert()[DFETF] = 0
PFStatus()[DFETF] = 1
Table 3-2. DFET Data Flash Configuration
Class Subclass Name Type Min Value Max Value
Default
Value
Unit
Permanent Fail DFET OFF Threshold I2 –500 0 –5 mA
Permanent Fail DFET Delay U1 0 255 5 s
3.6.2 Feature Enable/Disable
The feature is enabled when DFETF is set in Enable PF C.
3.7 Instruction Flash (IF) Checksum Permanent Fail
The device can permanently disable the battery if it detects a difference between the stored IF checksum and
the calculated IF checksum only following a device reset.
Status Condition Action
Normal Stored and calculated IF checksum match —
Trip Stored and calculated IF checksum after reset does not match.
PFStatus()[IFC] = 1
BatteryStatus()[TCA] = 1
BatteryStatus()[TDA] = 1
3.8 Data Flash (DF) Permanent Fail
The device can permanently disable the battery in case a data flash write fails.
Note
A DF write failure causes the gauge to disable further DF writes.
Status Condition Action
Normal Data flash write ok —
Trip Data flash write not successful
PFStatus()[DFW] = 1
BatteryStatus()[TCA] = 1
BatteryStatus()[TDA] = 1
