Texas Instruments BQ28Z610-R2 User Manual

SBS Cmd Name
Access
Proto-
col
Type Min Max Unit Note
SE US FA
0x30/31 ChargingVoltage() R R R Word U2 0 65535 mV
65535 = Request maximum
voltage
12.1.24 0x32/33 ChargingCurrent()
This read-word function returns the desired charging current.
SBS Cmd Name
Access
Proto-
col
Type Min Max Unit Note
SE US FA
0x32/33 ChargingCurrent() R R R Word U2 0 65535 mA
65535 = Request maximum
current
12.1.25 0x3C/3D DesignCapacity()
This read-word function returns the theoretical maximum pack capacity.
SBS Cmd Name
Access
Proto-
col
Type Min Max Default Unit
SE US FA
0x3C/3D DesignCapacity() R R/W R/W Word U2 0 65535
4400
mAh
6336
12.1.26 0x3E/3F MACSubcmd()
Writes to this command will set the MAC subcommand and is interchangeable with ManufacturerAccess().This
command is provided to allow for executing full MAC subcommands in a single transaction, as well as to provide
read-back verification of subcommands with a MACData() response. For a description of MAC subcommands
see Section 12.2.
SBS Cmd Name
Access
Proto-
col
Type Min Max Default Unit
SE US FA
0x3E/3F MACSubcmd() R R R Word — — — — —
12.1.27 0x40/0x5F MACData()
This is the data block for MACSubcmd() or MACSubcmd() commands.
SBS Cmd Name
Access
Proto-
col
Type Min Max Default Unit
SE US FA
0x40/5F MACData () R R R Block — — — — —
12.1.28 0x60 MACDataChecksum()
This is the checksum of the MACSubcmd() and MACData() bytes.
SBS
Cmd
Name
Access
Protocol Type Min Max Default Unit Note
SE US FA
0x60 MACDataCheckSum () R R R Byte — — — — —
The checksum is the 8-bit sum of the MSB and LSB of the command plus the (command length) bytes in
the buffer. The final sum is the bitwise inversion of the result. Since the length is part of the checksum, the
verification cannot take place until the length is written. The checksum and length must be written together as a
word to be valid.
12.1.29 0x61 MACDataLength()
This is the length for MACSubcmd() and MACData().
SBS
Cmd
Name
Access
Protocol Type Min Max Default Unit Note
SE US FA
0x61 MACDataLength() R R R Byte — — — — —
www.ti.com I2C Commands
SLUUCO0 – APRIL 2022
Submit Document Feedback
BQ28Z610-R2 71
Copyright © 2022 Texas Instruments Incorporated
