Texas Instruments BQ28Z610-R2 User Manual

Table 14-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Calibration
Cell Temperature
Model
0x441E Rpad I2 –32768 32767 0 —
Calibration
Cell Temperature
Model
0x4420 Rint I2 –32768 32767 0 —
Calibration Current Deadband 0x4446 Deadband U1 0 255 3 mA
Calibration Current Deadband 0x4447 Coulomb Counter Deadband U1 0 255 9 116 nV
Settings Protection 0x46A9 Protection Configuration H1 0x0 0x03 0x0 Hex
Settings Protection 0x46AA Enabled Protections A H1 0x0 0xFF 0x57 Hex
Settings Protection 0x46AB Enabled Protections B H1 0x0 0xFF 0x35 Hex
Settings Protection 0x46AC Enabled Protections C H1 0x0 0xFF 0x14 Hex
Settings Protection 0x46AD Enabled Protections D H1 0x0 0xFF 0x0C Hex
Settings Permanent Failure 0x46F7 Enabled PF A H1 0x0 0xFF 0x0 Hex
Settings Permanent Failure 0x46F8 Enabled PF B H1 0x0 0xFF 0x0 Hex
Settings Permanent Failure 0x46F9 Enabled PF C H1 0x0 0xFF 0x0 Hex
Settings Configuration 0x4600 FET Options H1 0x0 0xFF 0x20 Hex
Settings Configuration 0x4601 I2C Gauging Configuration H1 0x0 0x0F 0x04 Hex
Settings Configuration 0x4602 I2C Configuration H1 0x0 0xFF 0x01 Hex
Settings Configuration 0x4604 Power Config H1 0x0 0xBF 0x00 Hex
Settings Configuration 0x462D SOC Flag Config A H2 0x0 0x0FFF 0x0C8C Hex
Settings Configuration 0x462F SOC Flag Config B H1 0x0 0xFF 0x8C Hex
Settings Configuration 0x4648 IT Gauging Configuration H2 0x0 0xFFFF 0x14CE Hex
Settings Configuration 0x4659 Charging Configuration H1 0x0 0x3F 0x0 Hex
Settings Configuration 0x4695 Temperature Enable H1 0x0 0x03 0x03 Hex
Settings Configuration 0x4696 DA Configuration H1 0x0 0xFF 0x11 Hex
Settings Configuration 0x4705 Balancing Configuration H1 0x0 0xFF 0x01 Hex
Settings AFE 0x4698 AFE Protection Control H1 0x0 0xFF 0x70 Hex
Settings AFE 0x469E ZVCHG Exit Threshold I2 0 8000 2200 mV
Settings Charger 0x461F Device Address H1 0x0 0xFF 0xD4 Hex
Settings Charger 0x4620 Voltage Register H1 0x0 0xFF 0x0C Hex
Settings Charger 0x4621 Current Register H1 0x0 0xFF 0x0A Hex
Settings Charger 0x4624 Broadcast Pacing U1 0 255 15 s
Settings Manufacturing 0x43C0 Mfg Status init H2 0x0 0xFFFF 0x0000 Hex
Protections CUV 0x46AE Threshold I2 0 32767 2500 mV
Protections CUV 0x46B0 Delay U1 0 255 2 s
Protections CUV 0x46B1 Recovery I2 0 32767 3000 mV
Protections COV 0x46B3 Threshold Low Temp I2 0 32767 4300 mV
Protections COV 0x46B5 Threshold Standard Temp I2 0 32767 4300 mV
Protections COV 0x46B7 Threshold High Temp I2 0 32767 4300 mV
Protections COV 0x46B9 Threshold Rec Temp I2 0 32767 4300 mV
Protections COV 0x46BB Delay U1 0 255 2 s
Protections COV 0x46BC Recovery Low Temp I2 0 32767 3900 mV
Protections COV 0x46BE Recovery Standard Temp I2 0 32767 3900 mV
Protections COV 0x46C0 Recovery High Temp I2 0 32767 3900 mV
Protections COV 0x46C2 Recovery Rec Temp I2 0 32767 3900 mV
Protections OCC 0x46C4 Threshold I2 –32768 32767 6000 mA
Protections OCC 0x46C6 Delay U1 0 255 6 s
Protections OCC 0x46C7 Recovery Threshold I2 –32768 32767 –200 mA
Protections OCC 0x46C9 Recovery Delay U1 0 255 5 s
Protections OCD 0x46CA Threshold I2 –32768 32767 –6000 mA
Protections OCD 0x46CC Delay U1 0 255 6 s
Data Flash Summary www.ti.com
120 BQ28Z610-R2 SLUUCO0 – APRIL 2022
