Table 14-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Protections OCD 0x46CD Recovery Threshold I2 –32768 32767 200 mA
Protections OCD 0x46CF Recovery Delay U1 0 255 5 s
Protections AOLD 0x4699 Threshold H1 0x0 0xFF 0xF4 Hex
Protections AOLD 0x46D0 Recovery U1 0 255 5 s
Protections ASCC 0x469A Threshold H1 0x0 0xFF 0x77 Hex
Protections ASCC 0x46D1 Recovery U1 0 255 5 s
Protections ASCD 0x469B Threshold 1 H1 0x0 0xFF 0x77 Hex
Protections ASCD 0x469C Threshold 2 H1 0x0 0xFF 0xE7 Hex
Protections ASCD 0x46D2 Recovery U1 0 255 5 s
Protections OTC 0x46D3 Threshold I2 –400 1500 550 0.1°C
Protections OTC 0x46D5 Delay U1 0 255 2 s
Protections OTC 0x46D6 Recovery I2 –400 1500 500 0.1°C
Protections OTD 0x46D8 Threshold I2 –400 1500 600 0.1°C
Protections OTD 0x46DA Delay U1 0 255 2 s
Protections OTD 0x46DB Recovery I2 –400 1500 550 0.1°C
Protections UTC 0x46DD Threshold I2 –400 1500 0 0.1°C
Protections UTC 0x46DF Delay U1 0 255 2 s
Protections UTC 0x46E0 Recovery I2 –400 1500 50 0.1°C
Protections UTD 0x46E2 Threshold I2 –400 1500 0 0.1°C
Protections UTD 0x46E4 Delay U1 0 255 2 s
Protections UTD 0x46E5 Recovery I2 –400 1500 50 0.1°C
Protections PTO 0x46E7 Charge Threshold I2 –32768 32767 2000 mA
Protections PTO 0x46E9 Suspend Threshold I2 –32768 32767 1800 mA
Protections PTO 0x46EB Delay U2 0 65535 1800 s
Protections PTO 0x46ED Reset I2 0 32767 2 mAh
Protections CTO 0x46EF Charge Threshold I2 –32768 32767 2500 mA
Protections CTO 0x46F1 Suspend Threshold I2 –32768 32767 2000 mA
Protections CTO 0x46F3 Delay U2 0 65535 54000 s
Protections CTO 0x46F5 Reset I2 0 32767 2 mAh
Permanent Fail SOV 0x46FB Threshold I2 0 32767 4500 mV
Permanent Fail SOV 0x46FD Delay U1 0 255 5 s
Permanent Fail CFET 0x46FE OFF Threshold I2 0 500 5 mA
Permanent Fail CFET 0x4700 OFF Delay U1 0 255 5 s
Permanent Fail DFET 0x4701 OFF Threshold I2 –500 0 –5 mA
Permanent Fail DFET 0x4703 OFF Delay U1 0 255 5 s
Permanent Fail VIMR 0x4710 Check Voltage I2 0 5000 3500 mV
Permanent Fail VIMR 0x4712 Check Current I2 0 32767 10 mA
Permanent Fail VIMR 0x4714 Delta Threshold I2 0 5000 500 mV
Permanent Fail VIMR 0x4716 Delta Delay U1 0 255 5 s
Permanent Fail VIMR 0x4717 Duration U2 0 65535 100 s
Permanent Fail VIMA 0x4719 Check Voltage I2 0 5000 3700 mV
Permanent Fail VIMA 0x471B Check Current I2 0 32767 50 mA
Permanent Fail VIMA 0x471D Delta Threshold I2 0 5000 200 mV
Permanent Fail VIMA 0x471F Delay U1 0 255 5 s
Advanced Charge
Algorithm
Temperature
Ranges
0x465A T1 Temp I1 –128 127 0 °C
Advanced Charge
Algorithm
Temperature
Ranges
0x465B T2 Temp I1 –128 127 12 °C
Advanced Charge
Algorithm
Temperature
Ranges
0x465C T5 Temp I1 –128 127 20 °C
www.ti.com Data Flash Summary
SLUUCO0 – APRIL 2022
Submit Document Feedback
BQ28Z610-R2 121
Copyright © 2022 Texas Instruments Incorporated
