Class Subclass Name Type Min Max Default Description
Settings Configuration SOC Flag Config A H2 0x0000 0xFFFF 0x0C8C
Bit 0: TDSETV—Enable TD flag set by cell voltage threshold
0 = Disabled (default)
1 = Enabled
Bit 1: TDCLEARV—Enable TD flag clear by cell voltage threshold
0 = Disabled (default)
1 = Enabled
Bit 2: TDSETRSOC—Enable TD flag set by RSOC threshold
0 = Disabled
1 = Enabled (default)
Bit 3: TDCLEARRSOC—Enable TD flag clear by RSOC threshold
0 = Disabled
1 = Enabled (default)
Bit 4: TCSETV—Enable TC flag set by cell voltage threshold
0 = Disabled (default)
1 = Enabled
Bit 5: TCCLEARV—Enable TC flag clear by cell voltage threshold
0 = Disabled (default)
1 = Enabled
Bit 6: TCSETRSOC—Enable TC flag set by RSOC threshold
0 = Disabled (default)
1 = Enabled
Bit 7: TCCLEARRSOC—Enable TC flag clear by RSOC threshold
0 = Disabled
1 = Enabled (default)
Bit 8: Reserved
Bit 9: Reserved
Bit 10: FCSETVCT—Enable FC flag set by primary charge termination
0 = Disabled
1 = Enabled (default)
Bit 11: TCSETVCT—Enable TC flag set by primary charge termination
0 = Disabled
1 = Enabled (default)
Bit 15: 12: Reserved
Settings Configuration SOC Flag Config B H1 0x0000 0x00FF 0x008C
Bit 0: FDSETV—Enable FD flag set by cell voltage threshold
0 = Disabled (default)
1 = Enabled
Bit 1: FDCLEARV—Enable FD flag clear by cell voltage threshold
0 = Disabled (default)
1 = Enabled
Bit 2: FDSETRSOC—Enable FD flag set by RSOC threshold
0 = Disabled
1 = Enabled (default)
Bit 3: FDCLEARRSOC—Enable FD flag clear by RSOC threshold
0 = Disabled
1 = Enabled (default)
Bit 4: FCSETV—Enable FC flag set by cell voltage threshold
0 = Disabled (default)
1 = Enabled
Bit 5: FCCLEARV—Enable FC flag clear by cell voltage threshold
0 = Disabled (default)
1 = Enabled
Bit 6: FCSETRSOC—Enable FC flag set by RSOC threshold
0 = Disabled (default)
1 = Enabled
Bit 7: FCCLEARRSOC—Enable FC flag clear by RSOC threshold
0 = Disabled
1 = Enabled (default)
Settings Configuration
Charging
Configuration
H1 0x00 0x3F 0x00
Bit 0: CRATE—ChargeCurrent rate
0 = No adjustment to ChargingCurrent() (default)
1 = ChargingCurrent() adjusted based on FullChargeCapacity()/
DesignCapacity()
Bit 7:1: Reserved
Settings Configuration Temperature Enable H1 0x00 0x03 0x03
Bit 0: internal TS— Enable Internal TS
0 = Disable internal TS (default)
1 = Enable internal TS
Bit 1: TS1—Enable TS1
0 = Disable TS1
1 = Enable TS1 (default)
Bit 7:2: Reserved
Settings Configuration DA Configuration H1 0x00 0xFF 0x11
Bit 0: CC0—Cell Count
0 = 1 cell
1 = 2 cell
Bit 1: Reserved
Bit 2: Reserved
Bit 3: IN_SYSTEM_SLEEP—In-system SLEEP mode
0 = Disable (default)
1 = Enable
Bit 4: SLEEP—SLEEP Mode
0 = Disable SLEEP mode
1 = Enable SLEEP mode (default)
Bit 5: Reserved
Bit 6: CTEMP—Cell Temperature protection source
0 = MAX (default)
1 = Average
Bit 7: Reserved
www.ti.com Data Flash Values
SLUUCO0 – APRIL 2022
Submit Document Feedback
BQ28Z610-R2 99
Copyright © 2022 Texas Instruments Incorporated
