3-65
1) Open the “Anterior Analysis” tool (Fig. 2) by touching the “Anterior Analysis”
button (1) in the FREEZE menu window.
The zoom function is unavailable while the anterior
analysis tool is open. Apply the zoom function and
then open the anterior analysis tool to analyze the
enlarged image..
2) Select a tab (2) to display the “Angle Analysis” or “Iris Thickness” analysis
tool.
The measurement points and results are all deleted
when the analysis tool is closed and they cannot be
recovered.
3) Touching the “Close” button (3) closes the anterior analysis tool.
3-60
(Fig. 2)
(2)
(3)
