3-155
■
2) When the converted sonic velocity entry field (2) is touched, it is activated.
3) Enter converted sonic velocity using the keypad. Initially, it is set to 1640
m/s.
[Acceptable range]
Converted acoustic velocity: 1400 - 2000 m/s
4) Touch the “Display of Bias” button (3) to select the percentage bias (%) or
plus/minus bias (μm).
Using the keypad, enter the bias rate when the percentage bias is selected,
or the correction (4) when the plus/minus bias is selected.
Initially, the bias rate is set to 70 % and the correction is set to 0 μm.
[Acceptable range]
Bias rate: 60 – 130%
Correction: -600 – +450 mm
5) When a value is entered for one eye, the setting for the other eye is
automatically changed. Touch the “Initial Setting” button (5) to enter the
initial settings.
6) Touch the “OK” button (6) to apply the entered settings and close the
setting change screen. Touch the “Cancel” button (7) to discard the entered
settings and close the setting change screen.
c) Switching the measurement data display method
Set whether to display the measurement data as an actual measurement or
bias value.
Select Actual or Biased in Display Data (1) of the setting menu.
(Fig. 1)
(1)
3-111
