11
2.2.3 Output impedance
30Ω±5% (default), 100Ω±5%
2.2.4 Test Signal Level Monitor
Mode Range Monitor Accuracy
Voltage
10 mV
rms
– 2.00 V
rms
0.01 mV
rms
–10 mV
rms
±(3% of reading+0.5mV)
±(12% of reading+0.1mV)
Current
100μA
rms
– 66mA
rms
0.001μA
rms
– 100 μA
rms
±(3% of reading+5μA)
±(12% of reading+1μA)
2.2.5 Display Range
Parameter Range
L 0.01 nH to 9999.99 H
C 0.00001 pF to 999.999 mF
R, X, Z 0.01 mΩ to 99.9999 MΩ
B, G 0.01 nS to 999.999 S
D 0.00001 to 9.99999
Q 0.01 to 99999.9
θ Deg -179.999° to 179.999°
Rad -3.14159 to 3.14159
% -99.999% to 999.999%
2.3 Functions
2.3.1 Correction Functions
Open correction
Eliminates measurement errors due to parasitic stray admittance (C, G) of the
test fixture. Three frequency points or sweep frequency Open correction is
available.
Short correction
Eliminates measurement errors due to parasitic residual impedances (L, R) of
the test fixture. Three frequency points or sweep frequency Short correction is
available.
Load correction
Improves the measurement accuracy by using a device which value is accurately
known (a working standard) as a reference. Three frequency points load
correction is available.
2.3.2 Comparator function
10-bin sorting for the primary measurement parameter, and IN/ OUT decision output
for the secondary measurement parameter.
BIN1 to BIN9: Both primary and secondary measurement parameters are within
limits.
OUT BIN: Primary parameter is not within limits. Or primary parameter is within
limits, secondary parameter is not within limits, and AUX bin is off.
AUX BIN: Primary parameter is within limits, but whose secondary parameter
measurement result is not within limits.
If the secondary parameter limits are not set, TH2816B will not compare the
secondary parameter.
z Sorting Modes
Absolute deviation mode: absolute deviations are compared with bin limits.
Percent deviation mode: percent deviations are compared with bin limits.
z Bin Count
Each bin has a bin counter, counts from 0 to 999999.
