4.3.3.7 File Management
This function is the same as the function on the MeasDisplay page. (Refer to 4.3.1.8
File Management.)
4.3.3.8 Useful Tools
The Tools field on this page allows you to reset all the control settings to the default
settings.
Perform the following steps from the Meas Setup page to reset all control settings.
1) Move the cursor to the Tools field. The following softkey will be displayed.
 CLEAR
2) Press CLEAR, “Confirm: Clear All?” will be displayed in the message window.
The following softkeys will be displayed.
 NO
 YES
3) Press NO to cancel the CLEAR operation.
4) Press YES to reset all control settings to the default settings.
4.3.4 Limit Table
When you press PREVorNEXT, or LIMIT softkey, the Limit Table page will be
displayed. The Limit Table page allows you to set TH2816B's comparator.
TH2816B's built-in comparator can sort devices into a maximum of 10 bins (BIN1 to
BIN 9 and one OUT OF BINS) using a maximum of 3 pairs of primary limits and one
pair of secondary parameter limits. Also, devices whose primary parameter is within
limits, but whose secondary parameter measurement result is not within limits, can be
sorted into an AUXiliary BIN. The comparator function is especially useful when using
TH2816B with a component handler. These limit settings for bin sorting are only set
on this Limit Table page.
 Nominal Value for tolerance mode (NOMINAL)
 Measurement Function (FUNC)
 Comparator Function's Limit Mode (MODE)
 Comparator Function ON/OFF (COMP)
 Auxiliary bin ON/OFF (AUX)
 Low Limit Value of each bin (LOW)
 High Limit Value of each bin (HIGH)
 File Management (File)
 Useful Tools (Tools)
Each function is described in the following paragraphs.
The available fields and the softkeys which correspond to the fields on this page are
shown in Figure 4-14 and Figure 4-15.
