Example
WrtCmd(“DISP:DOWN 1”) Set display character to normal size.
Query Syntax
DISPlay:DOWN?
Query Response
Returned data format is :
<NR1><NL^END>
6.5.2 FREQuency Subsystem
The FREQuency command sets the oscillator frequency. The FREQuency? query
returns the current test frequency setting.
Command Syntax
<value>
FREQuency MIN
MAX
Where,
<value> The available values are listed as follows
50， 60，
100, 120, 200, 400, 500,
1000, 2000, 4000, 5000,
10000, 20000, 40000, 50000
100000,
50hz, 60hz,
100hz, 120hz, 200hz, 400hz, 500hz,
1khz, 2khz, 4khz, 5khz,
10khz, 20khz, 40khz, 50khz,
100khz
MIN Sets to the minimum value (50 Hz)
MAX Sets to the maximum value (100 kHz)
Example
WrtCmd (“FREQ 1KHZ”) Set test frequency to 1000 Hz
Note: When frequency list sweep measurement is sweeping, you cannot use this
command to set the frequency. If you do so, “Cannot Executed” will be
displayed in the message window.
Query Syntax
FREQuency?
Query Response
Returned Format is :
<NR1><NL^END>
