4.3 Detailed Operation
This Chapter provides information about the function of each page.
MeasDisplay
BinNo. Disp
MeasSetup
LimitSetup
SystemConfig
This Chapter describes the functions on each page in the order of the preceding list.
4.3.1 MeasDisplay Page
When you press HOME, the MeasDisplay page will be displayed. On this page, the
measurement results are displayed in large characters, and the following
measurement controls can be set from this page. (The field in parenthesis is used to
set the control function.)
Measurement Function (FUN)
Test Frequency (FRQ)
Oscillator Level (LEV)
Measurement Range (RANGE)
Measurement Speed (SPEED)
Short Correction (SHORT)
Open Correction (OPEN)
File Management (File)
Useful Tools (Tools)
There are ten fields on this page: <MeasDisplay>, FUN, FRE, LEV, RANGE, SPEED,
SHORT, OPEN, File and Tools. Each control function is described in the following
paragraphs.
This page also provides the oscillator level voltage/current monitor value information
in monitor areas on the displayed page. These conditions can be set from the Meas
Setup page.
The available fields and the softkeys which correspond to the fields on this page are
shown in Figure 4-5 and Figure 4-6 respectively.
Vm:999.1mV
<MeasDisplay>
Cp:206.335nF
D :0.00012
SHORT: OFF
OPEN: ON
SPEED: SLOW
RANGE: AUTO
LEV: 1.000V
FRQ: 1.0kHz
FUN: Cp-D
Im:1.364mA
BinNo
Tools
: Field
: Monitor
COUNTSWEEP
File
LCR
Figure 4-5. Available Fields on the MeasDisplay Page
To Next Page
