6.5.4 FUNCtion Subsystem
The FUNCtion subsystem command group sets the measurement function, the
measurement range, monitor ON/OFF control, and the deviation measurement
control. Figure 6-4 shows the command tree of the FUNCtion subsystem command
group.
FUNCtion :IMPedance [:TYPE] CPD
CPRP
CSD
CSRS
LSQ
LSRS
LPQ
LPRP
ZTD
ZTR
RX
:RANGe <value>
:AUTO ON (1)
OFF (0)
:DEV1 :MODE ABSolute
2 PERcent
OFF
:REFerence <value>
:FILL
Figure 6-4. FUNCtion Subsystem Command Tree
:IMPedance
The :IMPedance command sets the measurement function. The :IMPedance? query
returns the current measurement function.
Command Syntax
FUNCtion:IMPedance <function>
Where, <function> is:
CPD Sets function to Cp-D LPQ Sets function to Lp-Q
CPRP Sets function to Cp-Rp LPRP Sets function to Lp-Rp
CSD Sets function to Cs-D ZTD Sets function to Z-θ (deg)
CSRS Sets function to Cs-Rs RX Sets function to R-X
LSQ Sets function to Ls-Q ZTR Sets function to Z-θ (rad)
LSRS Sets function to Ls-Rs
Example
