4) Press ESC to cancel the load file operation.
4.3.1.9 Useful Tools
TH2816B displays the measurement data using a six digit floating point display
format. The fixed decimal point function is used to display the measurement data
using a fixed point display format. This function can also be used to change the
number of digits displayed.
Perform the following steps to use the xed decimal point function.
1) Move the cursor to the Tools field.
2) Press FIX A to fix the decimal point for the main parameter's data. The “_” mark
will be displayed at the decimal fixed point. Each time FIX A is pressed, the last
digit is dropped, the value is rounded off.
3) Press FIX B to fix the decimal point for the sub parameter's data. The “_” mark
will be displayed at the decimal fixed point. Each time FIX B is pressed, the value
is rounded off giving one less digit.
4) Press ↑↓ to switch the measurement result display characters between large
character and normal character.
5) Press KEY to lock the keyboard and “KeyLocked !” message will be displayed
in the message window.
6) Press KEY to unlock the keyboard and “KeyUnlock !” message will be
displayed in the message window.
Note: When the measurement function is changed, the fixed decimal point function
is automatically disabled.
