23
Rp (equivalent parallel resistance)
X (reactance)
Θ (phase angle)
The primary parameter measurement result is located on the upper line as two large
character lines on this page, and the secondary parameter measurement result is
located on the lower line as two large character lines on this page.
The combinations of primary and secondary parameters, including the equivalent
parallel and serial combinations, are listed in Table 4-1.
Table 4-1. Measurement Function
Primary
Parameter
Serial Mode Parallel Mode
Z
Z-Θr
Z-Θ°
C
Cs-D
Cs-Rs
Cp-D
Cp-Rp
L
Ls-Q
Ls-Rs
Lp-Q
Lp-Rp
R R-X
Front Panel Operation for Setting the Measurement Function
Perform the following steps to set the measurement function.
1) Use the CURSOR arrow keys to move the cursor to the FUN field. The following
softkeys will be displayed.
 Cp-D
 Cp-Rp
 Cs-D
 Cs-Rs
 NEXT
2) Select and press a softkey to set the measurement function. If the softkey you
want is not displayed, press NEXT to display the following set of softkeys.
 Ls-Q
 Ls-Rs
 Lp-Q
 Lp-Rp
 NEXT
3) Select and press a softkey to set the measurement function. If the softkey you
want is not displayed, press NEXT to display the following set of softkeys.
 Z-Θ°
 Z-Θr
 R-X

 NEXT
4) Select and press a softkey to set the measurement function. When NEXT is
pressed, the softkeys shown in step 1 will be displayed. Retry steps 1 through 4 if
you missed the function you were looking for.
4.3.1.2 Test Frequency
TH2816B operates from 50 Hz to 200 kHz with 37 typical frequency points which can
be selected through softkeys, or set through numeric entry keys.
Front Panel Operation for Setting the Test Frequency
Perform the following steps to set the test frequency.
