Tonghui TH2816B - 6.5 Command Reference

59
Table 6-2. Suffix Multipliers without Suffix Units
Type of Command Available Command Example
Deviation reference
value
FUNC:DEV1:REF
FUNC:DEV2:REF
:REF 100p
If the measurement function is Cp-D, then
deviation reference value for primary
parameter is 100pF
Standard value for
load correction
CORR:SPOTn:LOAD:STAN :STAN 0.1k,-12
If the measurement function for load
correction is R-X, then standard value for
load correction is 100Ωand -12Ω.
Limit value for list
sweep
LIST:BANDn :BAND1 A,100u,110u
If the measurement function for list sweep
measurement is L-Q, then the low limit for
primary parameter is 100uH, and the high
limit for primary parameter is 110uH.
Limit value for
comparator
COMP:TOL:NOM
COMP:TOL:BINn
COMP:TOL:SLIM
:NOM 100m
If the swapped measurement function for
comparator is Cs-Rs, then the nominal
value for Rs is 100mΩ.
Table 6-3. Suffix Units and Available Commands
Suffix Unit Available Command
HZ
FREQ
LIST:FREQ
CORR:SPOTn:FREQ
V, mV
VOLT
VOLT:LEV
LIST:VOLT
A, mA, uA LIST:BIAS
s,ms TRIG:DEL
For TH2816B, only the fixed frequency value and unit
configurations can be used. Refer to the FREQ subsystem
commands.
6.5 Command Reference
All commands in this reference are fully explained and listed in the following
functional command order.
TH2816B Subsystem Commands
◇ DISPlay ◇ FREQuency ◇ VOLTage ◇ FUNCtion
◇ APERture ◇ TRIGger ◇ FETCh?
◇ ABORt ◇ CORRection ◇ COMParator ◇ Mass MEMory
GPIB Common Commands
◇ *RST ◇ *TRG ◇ *IDN
The explanation of each subsystem command is patterned as follows.
1) Subsystem command name
2) Command Tree (Subsystem command only)
3) Compound Command Name
4) Command Description
5) Command Syntax
6) Example Using The Above Command Syntax
7) Query Syntax
8) Query Response
9) Example Using The Above Query Syntax
