6.5.1 DISPlay Subsystem
The DISPlay subsystem command group sets the display page. Figure 6-2 shows the
command tree of the DISPlay subsystem command group.
DISPlay :PAGE
MEASurement
BNUMber
MSETup
LTABle
SYSTem
:DOWN ON (1)
OFF (0)
Figure 6-2. Display Subsystem Command Tree
:PAGE
The :PAGE command sets the display page. The :PAGE? Query returns the
abbreviated page name currently displayed on the LCD screen.
Command Syntax
DISPlay:PAGE <page name>
Where, <page name> is:
MEASurement Sets display page to MeasDisplay
BNUMber Sets display page to BinNo. Disp
MSETup Sets display page to Meas Setup
LTABle Sets display page to Limit Table
SYSTem Sets display page to System Config
Example
WrtCmd(“DISP:PAGE MEAS”) Set display page to the MeasDisplay page.
Query Syntax
DISPlay:PAGE?
Query Response
Returned data format is :
<page name><NL^END>
Where,
<page name> Return the abbreviated name of the current display page as shown in
the preceding list.
:DOWN
The :PAGE command sets the display character size of the measurement results.
The :PAGE? Query returns the status of the display character size of the
measurement results.
Command Syntax
ON
DISPlay:DOWN OFF
1
0
Where,
1 (decimal 49) When the function is ON, normal character size is displayed.
0 (decimal 48) When the function is OFF, large character size is displayed.
