Auxiliary Bin on/off
Alarm on/off
Low/High Limits for Each Bin
Display page format
When TH2816B is turned on, TH2816B's auto load function will load the control
settings stored in file number 0. If there are no control settings stored in file number 0,
the power-on default settings will be used.
The following items are stored in internal nonvolatile memory without using the
LOAD/SAVE function.
Control settings on the User Correction page.
OPEN, SHORT, LOAD correction on/ff
OPEN, SHORT correction data for all test frequencies.
OPEN, SHORT, LOAD correction data at FREQ1, FREQ2, and FREQ3.
(OPEN correction data at each frequency, SHORT correction data at
each frequency, and LOAD correction reference data and actual data at
each frequency.)
Control settings on the System Config page.
Contrast of LCD
Information Beeper on/off
Comparator Alarm on/off
Password
Bus Mode
GPIB address
AutoFetch on/off
Perform the following steps to save the control settings to the internal non-volatile
memory.
1) Select and set all control settings on the MeasDisplay page.
2) Move the cursor to the File field.
3) Press SAVE. The message “Enter save number” will be displayed in the
message window.
4) Press ESC to cancel the number input operation.
5) Enter a save number from 0 to 11 using the numeric entry keys and press
ENTER. The message “Enter File Name” will be displayed in the message
window.
6) Press ESC to cancel the file name input operation.
7) Enter a file name using the numeric entry keys and ENTER to save the current
control settings. Numeric digits and characters can be inputted as a file name.
Perform the following steps to load the control settings from the internal non-volatile
memory.
1) Move the cursor to the File field.
2) Press LOAD. The message of available file(s) will be listed in the message
window as shown in Figure 4-9.
Figure 4-9. Available Files Message Window
3) Use the up and down cursor keys to select a file and press OK to load the file.
Load File:No.1
CBB13-325J
<Unnamed>
*TH2816B*
To Next Page
Loading...
