Limit Table
This display page provides the limit table settings for bin sorting. TH2816B
doesn't perform measurement from this page. To see the comparison results,
either the BinNo. Disp page or the Bin Count page should be used.
System Config
This display page provides the system information and control settings, such as
LCD contrast adjustment, PASSWORD, and GPIB ADDRESS etc.
