115
23. STANDARD EQUIPMENT
Remote Trigger (DLC1A)
Changing battery cells
• Remove the battery cell when the remote trigger is not to be used for a long time.
PROCEDURE
1. Pull the catch on the battery cover down. Remove the
battery cover.
2. Slide the coin-type battery and press as shown at right
to remove.
3. Insert a new battery with the + face up.
4. Fit the two prongs on the battery cover into the two
notches and close the battery cover. A click is heard
when the cover is in place.
