16.ROUTE SETTINGS
It is possible to delete a route or routes within the current JOB.
• A route that has not been output to an external device (displayed with *) cannot be deleted.
PROCEDURE
1. Select “Management” in <Menu>.
2. Select “Route" in <Management menu>.
<Route menu> is displayed.
3. Select “Route deletion”.
4. Align the cursor with the desired route and
press {}. "DEL" is displayed next to the
route ID.
• The numbers to the right represent the
number of data items in each route.
•= Use {
}/{} to move from page to
page.
• [...P] = Use {
}/{} to select individual
point.
•Press [TOP] to move to the first point number
on the first page.
•Press [LAST] to move to the last point
number on the last page.
5. Press [OK].
16.1 Deleting a Route
Menu
1.Meas
2.Management
3.Config
4.Calculation
Management menu
1.JOB
2.Route
3.Known point data
4.Simple meas. data
Route menu
1.Route setting
2.Route deletion
3.Comms output
4.View
5.IS deletion
*R1 20
R2 20
LINE01 15
LINE02 10
LINE03 DEL
LAST
TOP
...P
OK
