Topcon DL-501 User Manual

85
17. MANAGING KNOWN POINT DATA
4. Select “Comms input”.
5. Set "Location" to "USB".
6. Align the cursor with the file to be read in and
press {}.
Read starts and the number of read in files is
displayed on the screen. <Management
menu> is restored when read is complete.
•Press {ESC} to cancel.

Selectable options for the above data item are as follows.
• Location: SD/USB
It is possible to display all known point data in a JOB, as well as data, recorded using the misclosure
adjustment function, managed within each route.
PROCEDURE Displaying data in a JOB
1. Select “Management” in <Menu>.
2. Select “Known point data” in <Management
menu>.
3. Select “View”.
17.3 Viewing Known Point Data
Comms input
Location :USB
OK
Known point data menu
1.Key in coord
2.Comms output
3.View
4.Deletion
5.Initialize
DL-501_E.book 85 ページ ２０１５年９月１７日 木曜日 午後１時２１分
