19.CHANGING THE SETTINGS
This section explains the contents of parameter settings, how to change these settings, and how to
restore default settings.
Each item can be changed to meet your measurement requirements.
Instrument constants are explained in a different chapter.
"21.2 Tilt Sensor", "21.3 Adjusting the Reticle"
Items set and options (*: Factory setting)
Measurement mode (Meas mode): Single*, Repeat, Average, Rapid
AVG times (only displayed when: 1 to 20
"Average" selected above)
Rec cond.: Yes*, No
SD mirroring (only displayed when: On/Off*
"Yes" selected above)
Height resolution (Ht. reso.): 0.01mm/0.0001ft*, 0.1mm/0.001ft, 1mm/0.01ft
Distance resolution (Dist reso.): 0.001m/0.01ft*, 0.01m/0.1ft, 0.1m/1ft
Earth curvature and refraction correction (C&R):
No*, K=0.142, K=0.20
Auto Focus setting. (A.F.setting): Yes*, No
Tilt warning (Tilt warn): Yes*, No
• "Rec cond." cannot be changed for a JOB already containing route data.
• There is no "A.F. setting" for the DL-501 Standard.
19.1 Observation Conditions
Config menu
1.Obs.condition
2.Instr.config
3.Comms setup
4.Tilt offset
5.Unit
Config menu
6.Date and time
Meas mode :Single
Rec cond. :Yes
SD mirroring:Off
Ht reso. :0.01mm
Dist reso. :0.001m
C&R :No
A.F.setting :Yes
Tilt warn :Yes
