41
11. SIMPLE MEASUREMENT
7. Check point ID, double-run setting, and
measurement results.
Press [OK].
8. Measure foresight.
9. Check point ID, double-run setting, and
measurement results.
Press [OK].
Results are recorded and the screen in step 8
is restored.
• When "Auto rec" is set to "Yes", results are
displayed for approx. 1 sec. before the
screen in step 8 is restored.
10. Press [TURN P] on page 2 to set the
previously measured foresight as a turning
point.
11. Move the DL to the next position.
Repeat from step 5 using the foresight
measured in step 8 as the new backsight.
OK
BS Go
BS0001
Rh 2.45678m
Hd 17.891 m
S
FOCUS
FS Go
FS0001
Rh
Hd
PT.ID
CNFGTILT
S
P1
OK
FS Go
FS0001
Rh 2.34567m
Hd 12.345 m
Z 1001.23456m
S
TURN P
FS Go
FS0001
Rh 2.34567m
Hd 12.345 m
Z 1001.23456m
S
"Auto rec" set to "No"
"Auto rec" set to "Yes"
FS Go
FS0001
Rh
Hd
TURN PINPUT
S
P2
