Topcon GR-5 User Manual

Receiver Setup
P/N 7010-1004
4-3
To set up the Rover receiver (Figure 4-2):
1. If needed, attach the quick disconnect to the bipod/range pole.
2. Attach the GR-5 receiver to the quick disconnect. Make sure the
receiver locks into place.
3. Attach the antenna to the modem antenna connector.
Figure 4-2. Connect GR-5 Receiver to Bipod
NOTICE
Use a bipod during post-process surveys to ensure
the antenna/receiver does not move during data
logging.
Lock
GR-5 Recevier
5/8 inch Screw
Quick Disconnect (Optional)

Topcon GR-5 Specifications

General

Brand	Topcon
Model	GR-5
Category	Receiver
Language	English
