Receiver and File Maintenance
GR-3 Operator’s Manual
5-16
5. Click the Device tab and set the Device Type as “Receiver’s
Power Board”. Then click Get from Device for device
information (Figure 5-13).
Figure 5-13. Set Device Type
6. Click the Program tab and set the Capture Method to “Soft
Break Capture” (recommended) (Figure 5-14).
Figure 5-14. Program Tab Settings
7. Browse for and select the Power board’s RAM file (Figure 5-14).
8. Click Load and wait until 100% of the power board file loads into
the receiver.
NOTICE
If you selected an incorrect file, an error message
displays at the bottom of the dialog box. Select the
correct file.
