Getting Acquainted
P/N 7010-0526
1-9
The FN button switches the receiver between information modes and
post-processing modes, starts/stops data recording, and changes the
baud rate of the serial port to 9600. See “MINTER Operation” on
page 4-7 for more information.
Table 1-1 describes the REC LED status when using the FN button
when data recording is off or on.
Table 1-1. FN Button Operations and REC LED Status
FN Key REC LED Status
When data recording is off, and the FN key is...
Not pressed
No light No data recording.
Orange blink Internal file system test in progress.
Red No free memory; hardware problem
with data recording.
Pressed for < 1
second
If FN key mode is “LED blink mode switch”
Orange Release to change information mode.
If FN key mode is “Occupation mode switch”
Orange No FN.
Pressed for 1–5
seconds
If FN key mode is “LED blink mode switch”
Green Release to start data recording (post-
processing occupation mode undefined).
If FN key mode is “Occupation mode switch”
Green Release to start recording (Kinematic or
Static post-processing occupation mode)
Pressed for 5–8
seconds
Red Release to turn serial port A baud rate to
9600 bps.
Pressed for > 8
seconds
No light No FN.
