Configuring the Receiver
P/N 7010-0526
3-15
PC-CDU is Personal Computer-Control Display Unit software used
to manage the various functions of your receiver. The full range of
PC-CDU configuration and FN is outside the scope of this manual.
For more information on any of the procedures in this section or on
PC-CDU, refer to the PC-CDU User’s Manual available on the TPS
website.
PC-CDU configures the various parts of the receiver, saving the
settings in the receiver’s memory. These settings will be reflected
when you use the MINTER. The full range of PC-CDU configuration
and FN is outside the scope of this manual.
Once you have established a connection between the receiver and the
computer, you will be able to:
• configure the receiver and its components
• send commands to the receiver
• download files from the receiver’s memory
• load a new OAF and other configuration files to a receiver
The following Base and Rover configurations are recommended for
the most common applications. However, you can select
configuration parameters as needed for your particular jobsite.
1. Connect the receiver and computer as described in “Connecting
the Receiver and a Computer” on page 2-14.
2. Start PC-CDU on your computer. The PC-CDU main screen
displays (Figure 3-14).
Notice that the lower-left hand corner shows the receiver status as
“Disconnected”.
WARNING
Do not make other changes without consulting the
PC-CDU Reference Manual.
