Configuring the Receiver
P/N 7010-0935
3-7
Figure 3-6. Base Configuration for RTK Surveys – Ports
10. Click the Advanced tab, and then the Multipath tab. Set the
following parameters, and click Apply (Figure 3-7).
• Code multipath reduction – enable
Baud rate Select a baud rate to use for transmitting differential
messages from the receiver board to the modem module.
The baud rate must match the modem’s serial port speed.
RTS/CTS Select to enable handshaking.
Table 3-2. Receiver Parameters for the Ports Tab (Continued)
Parameter Base Receiver
Net-G3A_OM_Book.book Page 7 Thursday, May 14, 2009 8:49 AM
