100
TROUBLESHOOTING
Turn off the unit? Displayed to confirm whether to move the chinrest and measuring head to their
last positions in R/K measurement mode.
Perform air check or Turn off the
unit?
Displayed to confirm whether to perform air check or whether to move the chin-
rest and measuring head to their last positions in T/P measurement mode.
Air checked. Press OK to
continue.
Displayed when normal air check operation is confirmed.
Confirm abnormal action(-) of air
check
Displayed when an anomaly occurred during air check. Check the measuring
nozzle for any foreign matter.
Confirm abnormal action(+) of air
check
Displayed when an anomaly occurred during air check. Check the measuring
nozzle for any foreign matter.
Please don't turn the main switch
off until the unit stops.
Indicates that termination is in process.
The unit stops completely.
Please turn the main switch off.
Indicates that termination is completed.
Please be sure to perform setting
of safety stopper before
measuring, for patient safety.
Display this message at power
on also from the next time?
Displayed when urged to set safety stopper. Set up safety stopper.
Please set the limit within 0 mm
to 30 mm.
Displayed on the Safety Stopper screen, when the z-axis position is outside the
0-30mm.
Range of Input value is 1-10 Displayed when the "Cont. Cycle" in "REF/KRT" of the "Initial" in R/K measure-
ment mode is set to a value out of the specified input range. Enter a value
within the input range.
Range of Input value is 2-10 Displayed when the "Cont. Cycle(TONO)" or "Cont. Cycle(PACHO)" in
"TONO/PACHO" of the "Initial" in T/P measurement mode is set to a value out
of the specified input range. Enter a value within the input range.
Range of Input value is 0-24 Displayed when the "Line space" in "Common" of the "Print" is set to a value
out of the specified input range. Enter a value within the input range.
Range of Input value is 1-99 Displayed when the "Device ID number" in "Common" of the "Initial" is set to a
value out of the specified input range. Enter a value within the input range.
Chinrest Error Displayed when the chinrest is not correctly connected or not connected at all.
Patient ID is required. Please set
patient ID.
Displayed when the output operation is requested and the setting "Required
patient ID" is "ON" in "Common" of the "Initial", but the patient ID is not input-
ted. Enter the patient ID and then request the output operation.
Operator ID is required.
Please set Operator ID.
Displayed when the output operation is requested and the setting "Operator ID
request" is "ON" in the "Operator ID", but the operator ID is not inputted. Enter
the operator ID and then request the output operation.
Output not set Displayed when all output settings are OFF.
No print data, please confirm
measurement mode.
Displayed when the measurement mode in measuring differs from the mea-
surement mode in printing.
LAN output... LAN data output is in process.
LAN hostname error Failed to resolve the host name of the destination (to be connected with the
shared folder). Confirm the inputted host name or DNS server address.
LAN init error Failed to reset the LAN connection. Confirm that the LAN cable connection and
the LAN setting are in the correct way.
LAN mount error Failed to connect to the shared folder. Confirm the address, folder name, user
name and password of the destination (to be connected with the share folder).
Permission error of folder Failed to create the file. Confirm that write permission to the share folder is set
correctly.
Not enough storage space Failed to write to the file. Check the free space capacity at the save location.
LAN start error Failed to reset the LAN connection. Confirm that the LAN cable connection and
the LAN setting are in the correct way.
