76
OPTIONAL OPERATIONS
OUTPUT USING RS-232C
This instrument can output data to a PC, etc. via the RS-232C interface.
1 Connect the interface cable to RS-232C OUT.
Refer to "CONNECTING EXTERNAL I/O TERMINALS" on page 26.
2 Set up of data communication settings.
For details, refer to "DATA COMMUNICATION (COMM)" on page 90.
3 Perform measurements.
4 Tap the button on the control panel.
When output is completed, "RS-232C SUCCESS" is displayed on the screen.
INPUT USING USB
This instrument can input ID numbers from a bar code reader, etc. via the USB.
1 Check the connection of USB IN.
For connection, refer to "CONNECTING EXTERNAL I/O TERMINALS" on page 26.
2 Input ID numbers from the external device.
The inputted ID numbers are displayed on the screen.
OUTPUT USING LAN
This instrument can output data to a PC, etc. via the LAN interface.
1 Connect the network cable to LAN OUT.
For connection, refer to "CONNECTING EXTERNAL I/O TERMINALS" on page 26.
2 Set up of LAN connection settings.
For details, refer to "LAN CONNECTION (LAN)" on page 90.
3 Perform measurements.
4 Tap the button of the control panel.
Output is completed.
NOTE
For explanation of messages during communication refer to the
"MESSAGE LIST" on page 99.
