90
SETTING FUNCTIONS ON SETUP SCREEN
DATA COMMUNICATION (COMM)
Comm contains settings related to data output with the external device.
LAN CONNECTION (LAN)
LAN contains settings related to data output via LAN.
Descriptions Options Details Initial value
Output data
REF Only REF data are output.
ALL
KRT Only KRT data are output.
REF/KRT REF/KRT data are output.
TONO Only TONO data are output.
T/P TONO/PACHO data are output.
ALL All measurement value is output.
Format
(In case of selecting of
REF, KRT and R/K output)
OLD OLD TOPCON format
OLD
NEW NEW TOPCON format
STD1 TOPCON STD1 format
STD2 TOPCON STD2 format
STD3 TOPCON STD3 format
STD4 TOPCON STD4 format
Format
(In case of selecting of
TONO and T/P output)
MODE1 Average value output format
MODE1
MODE2 Latest value output format
STD1 TOPCON STD1 format
STD2 TOPCON STD2 format
STD3 TOPCON STD3 format
STD5 TOPCON STD5 format
Format
(In case of selecting
of ALL output)
STD3 TOPCON STD3 format STD3
Output port
OFF Output port is disabled.
OFF
ON Output port is enabled.
Baudrate
2400bps Baudrate value: 2400bps
9600bps
9600bps Baudrate value: 9600bps
Descriptions Options Details Initial value
LAN connection
OFF LAN connection is off.
OFF
ON LAN connection is on.
XML file output
OFF XML file is not outputted.
ON
ON XML file is outputted.
Shared folder setting
Shared folder
(up to 32 characters)
User name
(up to 32 characters)
Password
(up to 16 characters)
Set by
keyboard display
Path and permission to the shared folder is set.
-
IP address setting
FIX Assign IP address manually.
FIX
AUTO Assign IP address automatically.
IP address
0. 0. 0. 0
Set by number display
IP address of PC to output data. 0.0.0.0
Subnet mask
0. 0. 0. 0
Set by number display
Subnet mask address of TRK-2P. 0.0.0.0
Default gateway
0. 0. 0. 0
Set by number display
Default gateway address of TRK-2P. 0.0.0.0
Primary DNS server
0. 0. 0. 0
Set by number display
Primary DNS Server number. 0.0.0.0
Secondary DNS server
0. 0. 0. 0
Set by number display
Secondary DNS Server number. 0.0.0.0
