BASIC OPERATIONS
BASIC OPERATIONS
MEASUREMENT IN REF/KRT→TONO/PACHO CONTINUOUS MEASUREMENT MODE
2 Alignment starts automatically, and measurement is performed. Move the measuring head to
the other eye measurement position automatically and measurement is performed. The mea-
surement results are displayed.
NOTE
• When the measuring head has reached the limit of movement (vertical/lat-
eral directions), a yellow-colored limit mark appears on the control panel
corner, showing it is the movement limit in that direction. Tap the display to
move the measuring head to a position that aligning is possible.
• When the measuring head is at the limit of movement in the forward direc-
tion, "TOO CLOSE" is displayed and the buzzer sounds, and when it is at
the limit of movement in the backward direction, "TOO FAR" is displayed.
Using the button, move the measuring
head to a position that aligning is possible.
NOTE
• When the "Full Auto" of "R/L move" is selected in "REF/KRT" of the "Ini-
tial", the instrument measuring head moves automatically to the other eye
side for measuring. If the patient closes or blinks their eyes at the time of
the right-and-left eye change, the change may be unable to be performed
correctly.
If the "Manual" of "R/L move" is selected, press the button or
button of the other eye side. If the "Auto(RL)" of "R/L move" is selected,
the measuring head moves automatically to the other eye side, however a
measurement is not performed.
PatientID
/3
/3
/3
/3
13.75
13.75
/3
/3
/3
/3


1
1
R
R
S
S
S
S
S
S
C
C
C
C
A
A
A
A
C
C
A
A
K
K
R
1
R1
R
2
R2
A
1
A1
R
R
S
S
C
C
A
A
K
K
R
1
R1
R2
R2
A
1
A1
VD
VD
mm
mm
TO
PC
ONT
AROU
TOPCONTAROU
R/K T/P
MODE
Pleasetouch
pupilonthescreen.
Limit mark
